The Space Race features six distinct reverb engines, each with its own set of features and controls. Tap the center button to advance to the next reverb engine.

REVERB ENGINES:

MOD: Modulated chamber reverb. The Tweak knob controls the speed and depth of the pitch modulation.

SHIM: Reverb with a pitch-shift component. The Tweak knob controls the pitch shift interval, either an octave down or an octave up.

LOFI:  Dirty and filtered reverberation, like the echo you might get out of a broken karaoke machine.  Reverb and Space control the decay and pre-delay, respectively, while Tweak controls the amount of dirt and grit present in the reverb signal.

PLATE: Bright and present reverb based on both a mechanical plate design and the early electronic plate reverb algorithms. Tweak adjusts the high-frequency damping of the reverb signal.

SPRING: You know what this one is. Drippy and wet, this spring reverb simulation is great for both subtle and not-so-subtle effects. Reverb adjusts the size of the reverb tank, Space controls the “dwell” or input signal level, and Tweak controls the tone of the reverb signal.

ANALOG: Electronic reverb based on an obscure bucket-brigade echo circuit. This mode lacks all of the smoothing and diffusion of more modern reverb types, so you can hear each individual echo in the reverb tail. Reverb controls the delay time, Space controls the repeats of the echo, and Tweak adds an adjustable modulation effect.

PRESETS

Four built-in presets give you quadruple the tones in a single footprint. Add a MIDI controller for 16 presets.


AUTO TRAILS

Set the pedal trails from 0-10 seconds. The pedal will automatically perform a smooth fade at your chosen time.

NEO MORPH

Seamlessly morph between different knob settings on the fly using the built-in ramp footswitch, expression pedal, Neo Footswitch, or MIDI controller.

MIDI CONTROL

Every knob and setting on the pedal is controllable using MIDI. Connect using the MultiJack and our Neo Link or directly to any Disaster Area Gen3 controller.

MULTIJACK

Connect an expression pedal, Neo Footswitch, or MIDI controller to this jack to add performance control to your pedal.


USB PORT

Every Neo Series pedal features a USB port for MIDI control and firmware updates.

Mono input

Dual output (mix signal on tip, dry signal on ring)

Input Impedance: 1M ohms

Output Impedance: 560 ohms

DC 9V only, 100mA or greater

Requires isolated DC power supply

4.7” x 2.6” x 1.5” H x W x D not including knobsSix reverb engines

Four presets, expandable to 16 with a MIDI controller

MultiJack enables expression pedal, foot switch, or MIDI input

Neo Morph allows controlling all knobs from expression or MIDI

USB port for firmware updates and USB MIDI
